U-Pilot

U-Pilot

U-Pilot by Airelectronics is on-board hardware that can fly fixed and rotary wing aircrafts equally during the extent of its mission: from take-off to landing, always in automatic mode with a manual override option.

$6,554.00

Choose Your Package

SKU: AIREUPLT Category: Tags: , ,
  • Description
  • Specifications

Description

U-Pilot by Airelectronics is on-board hardware that can fly fixed and rotary wing aircrafts equally during the extent of its mission: from take-off to landing, always in automatic mode with a manual override option.

The advanced technology used and its dual CPU approach allows to update our attitude estimation and control loop lightning fast (1 kHz), allowing the control of the most unstable and dynamic platforms while we still manage to handle several payloads in parallel.

Its radio-link operates in 900MHz frequency band which allows ranges in excess of 100 km. Although if you were to be too ambitious, the autopilot would return the system home automatically.

And of course, if as our costumer you want some extra capability, we would develop it promptly for you.

  • Its hardware architecture is safe by design: a CPU is solely dedicated to fly the plane without making any blocking operation.
  • Top of the line MEM sensors: up to ±16G and 2000 °/s dynamics detection
  • Up to 31 PWM outputs and 4 RS-232 serial port for all your needs.
  • Automatic return home functionality in case of loss of COMMs
  • Up to 100 km of data-link range
  • Up to 200 Way-points
  • Soaring capability to give you more time in air
  • Fully automatic mission control
  • Automatic Take-off and Landing
  • 3 Available 12-bit ADC channels
  • Great GPS performance with its on-board 12 channel receiver

U-Pilot Specifications Sheet

U-Pilot Manual

View specifications here.
